GCD16-01G 蓄能器式液控缓闭止回蝶阀
分享到:
GCD16-01G 蓄能器式液控缓闭止回蝶阀
产品详情
产品用途
HD7X41X 型 PN6~PN16 蓄能器式液控缓闭止回蝶阀主要用在热电厂并联机组和煤气余热发电机组上,用以作为保护系统安全得紧急切断阀门。

主要外形和连接尺寸

DNPNLL1L2L3L4法兰连接尺寸
4000.62165561449320440GB/T17241
GB/T9113
1.02165561449330440
1.62165561449345440
4500.62225561449370440
1.02225561449380440
1.62225801449395490
5000.62295801449400440
1.02295801449410490
1.62295801449425490
6000.62675801449440490
1.02675801449460490
1.62676251820470490
7000.62926251449436490
1.02926251820550545
1.62926251820570545
8000.63186251820625490
1.03186251820640545
1.63186251820660545
9000.63306251820700545
1.03306251820710545
1.63306751820725610
10000.64106251820760610
1.04106751820770610
1.64106752180790610
12000.64706751820875610
1.04706752180890610
1.64707292180915720
14000.653072921801000720
1.053072921801020720
1.653078121801045960
16000.660078121801120720
1.060078121801140960
